Product Feature

• ● Reliable AC Traction motor and AC Pump motor, which are brushless and maintenance-free.



• ● Reliable AC Traction controller and AC Pump controller self-protecting and maintenance-free.



● Interactive communication multifunctional LED meter with a friendly interface, display mass information,

password handing and maintenance-free.

• ● Standard CAN BUS interface for simple and reliable communication.



• ● Travel speed and lifting speed closed-loop control.



• ● Powerful security, self-braking on-ramp.



• ● The new technology of dynamic signal load sensing in hydraulic systems.



• ● Travel speed normal/cutback choice function.



● Electromagnetic compatibility reaches international standards.

The main parameter

Identification	Series		G Series
	Model Designation		CPD30	CPD35
	Load Capacity	lbs	6000	7000
	Load Center	in	24	24
	Operator Type		Seated	Seated
Dimensions	Overhead Guard Height	in	87	87.2
	Length to fork face	in	98	101
	Overall Width	in	49	48.9
	Turning Radius (In standard battery compartment)	in	87	89.4
	Right Stack Aisle width (Pallet size 40x40in，clearance:7.9in）	in	153	156
	Right Stack Aisle width (Pallet size 47.2×47.2in，clearance:7.9in）	in	161	164
Wheels, Chassis	Tire Type		Pneumatic	Pneumatic
Weight	Total Approximate Weight(W/O battery)	lbs	10604/7627	12125/9149
Performance	Travel Speed,loaded/unloaded	mph	9.3/9.6	9
	Battery Voltage/rated capacity(5h)	V/Ah	80/480	80/560
	Drive Motor – 60 Min. Rating	HP	22.6	22.6
	Pump Motor – 15 Min. Rating	HP	17.7	17.7
	Drive Motor Control Method		MOSFET/AC	MOSFET/AC
	Controls		ZAPI	ZAPI
