Product Feature
-
- ● Reliable AC Traction motor and AC Pump motor, which is brushless and maintenance-free.
-
- ● Reliable AC Traction controller and AC Pump controller self-protecting and maintenance-free.
● Interactive communication multifunctional LED meter with a friendly interface, display mass
information, password handing and maintenance-free.
-
- ● Standard CAN BUS interface for simple and reliable communication.
-
- ●Travel speed and lifting speed closed-loop control.
-
- ● Powerful security, self-braking on-ramp.
-
- ● The new technology of dynamic signal load sensing in hydraulic systems.
-
- ● Travel speed normal/cutback choice function.
-
- ● Electromagnetic compatibility reaches international standards.
The main parameter
| Identification | Series | G Series | |||||
| Model Designation | CPD10 | CPD15 | CPD18 | CPD20 | CPD25 | ||
| Load Capacity | lbs | 2000 | 3000 | 3500 | 4000 | 5000 | |
| Load Center | in | 24 | 24 | 24 | 24 | 24 | |
| Operator Type | Seated | Seated | Seated | Seated | Seated | ||
| Dimensions | Overhead Guard Height | in | 84 | 84 | 84 | 85 | 85 |
| Length to fork face | in | 81 | 81 | 81 | 90 | 90 | |
| Overall Width | in | 43 | 43 | 43 | 47 | 47 | |
| Turning Radius (In standard battery compartment) | in | 69 | 69 | 69 | 79 | 80 | |
| Right Stack Aisle width (Pallet size 40x40in，clearance:7.9in） | in | 131 | 131 | 131 | 143 | 144 | |
| Right Stack Aisle width (Pallet size 47.2×47.2in，clearance:7.9in） | in | 139 | 139 | 139 | 151 | 152 | |
| Wheels, Chassis | Tire Type | Pneumatic | Pneumatic | SE/Pneumatic | Pneumatic | Pneumatic | |
| Weight | Total Approximate Weight(W/O battery) | lbs | 6440/4940 | 6440/4940 | 7100/5360 | 9170/6750 | 9590/6950 |
| Performance | Travel Speed,loaded/unloaded | mph | 9.3/9.9 | 9.3/9.9 | 9.3/9.9 | 9/9.3 | 9/9.3 |
| Battery Voltage/rated capacity(5h) | V/Ah | 48/480 | 48/400 | 48/480 | 48/700 | 48/700 | |
| Drive Motor – 60 Min. Rating | HP | 11 | 11 | 11 | 15.4 | 15.4 | |
| Pump Motor – 15 Min. Rating | HP | 14.2 | 14.2 | 14.2 | 20.1 | 20.1 | |
| Drive Motor Control Method | MOSFET/AC | MOSFET/AC | MOSFET/AC | MOSFET/AC | MOSFET/AC | ||
| Controls | ZAPI | ZAPI | ZAPI | ZAPI | ZAPI | ||
